TANAKA Precious Metals maximizes the potential of precious metal materials

Minamikawa: What do you think of the role that TANAKA Precious Metals should play under such circumstances?

Abe: We are a manufacturer of cutting-edge materials using precious metals. One of our roles is to maximize the potential of precious metal materials. Another is to contribute to the industry by using processing technology cultivated through many years of technological development.

The first point for maximizing the potential of materials is the development of cutting-edge materials that take advantage of the unique material qualities of precious metals, such as low resistance, high electrical conductivity, low chemical reaction, and reliability.

There is no limit to the technological development of adding functionality not only to pure materials, but also alloys and additives. In addition, although precious metals have an impression of being expensive, we will respond to industry needs while drawing a roadmap for cost reduction, such as reducing the content of precious metals.

Another point is materials other than precious metals that we have handled over our long history, and a typical example of this is bonding wire for power semiconductors, which includes products made from aluminum and copper-based materials. We originally supplied gold wire for semiconductors, and by applying that processing technology, we were the first to develop and mass produce aluminum bonding wire as well.

The strength of TANAKA Precious Metals is that we can apply our technological development capabilities, with precious metals at the core, to develop materials other than precious metals that suit the applications.

We would like to grasp the trends in the industry as a whole, including final applications, while continuing to develop cutting-edge materials ahead of time.

Minamikawa: In terms of materials development, we are now in an era where new materials are being developed with the help of AI—and I am not just talking about semiconductors.

You may be able to create new materials that do not fit within the framework of semiconductors. I would very much like to see you do that.

Abe: Thank you for the great idea.

TANAKA Precious Metals will celebrate its 140^th anniversary in July 2025, and a new search team called “Dock2085” has been established within the company with the aim of becoming a 200-year-old company.

Thus, we are researching interesting functional expressions, even if their applications not yet known, and exploring business fields in which precious metals have never been involved before. We will continue to promote both the strengthening of our current business and the sowing of seeds for the future.

Thank you very much for the supportive comments. We hope to continue to do our best as one of the companies that can contribute to the semiconductor industry.

TANAKA Precious Metals’ Products for Power Devices, Offering Total Solutions

•
•

Bonding Wires

Al Wire/Ribbon

• Good bondability
• Good moisture resistance

Cu Wire/Ribbon

• Low electrical resistance
• High fusing current

Click here for more information

•
•

Die Bonding Materials
(Silver Adhesive Pastes)

Ag-Adhesive

• Good adhesion to bare Si

Hybrid Ag-Adhesive

• High thermal conductivity
• Good reliability

Pure sinter-Ag

• High thermal conductivity
• High Hot-DSS

Click here for more information

•
•

Active Brazing Filler Metall/Copper Composite Material

Thick Cu circuit formation

• Etching-less method
• Possible to thinner brazing metal layer

Binderless

• Easy maintenance of the furnace

Shorter heat processing time

• Lower brazing temperature

Click here for more information

Various Types of Electrodes and Metalized Layers

Plating Processes

Metalized Layers for Bonding Pads

• Ni/Pd/Au, Ni/Au, Ag, etc.
• Proposals appropriate for material combinations of bonding wires and pads
• Balance of high reliability and high productivity

Rear-side Electrodes for Ohmic Contacts

• Ni/Au, etc.
• Limit wafer warping through low stress
• Good die-attach bondability

For Lead Frames, Copper Clips, and PCBs

• Ni/Pd/Au, etc.
• Prevent spreading of Ni layer
• Make Au layer into a thin film and reduce overall costs

Plating Processes

Click here for more information

Sputtering Targets

Various Types of Precious Metal and Alloy Targets

• Pure precious metal targets such as Au, Ag, Pt, Pd, and Ir
• Precious metal alloy targets

• High-purity targets suitable for various types of electrodes and metalized layers
• Deposition that is free of pinholes, oxides and gases
• Silver alloy targets with high environmental resistance (sulfur resistance and humidity resistance)

Sputtering Targets

Click here for more information
